Specifications:

Operating Temperatures: -4°F (-20°C) to + 149°F (65°C) without Battery Backup Module or CMA; -4°F (-20°C) to + 140°F (60°C) with Battery Backup Module and/or CMA; Humidity: To 95% non-condensing.
Power: Fully automatic 100 to 240 VAC, 50 or 60 Hertz, 55 watts; no rewiring, switching or adjustments required. Power supply meets UL, CSA, TUV and VDE standards.
Weatherproofing / Foreign Object Protection Standards: Meets IP 31, IEC Standard. "Degrees of Protection provided by Enclosures," IEC 529.
Interference Suppression: 100% sensor coil Faraday shielding; special Garrett built-in circuitry for noise suppression and ignoring x-ray monitor horizontal sync.
Traffic Counter: Built-in and resettable with current reading available on LCD panel.
Synchronization: Multiple channels permit several CS 5000s and other Garrett detectors to operate simultaneously in close proximity.
Alarms: Ready light indicates unit is operational; alarm lights and audible alarms are activated when the target amount of metal is detected; LED bar graph indicates amplitude of alarm signal.
Tamper-Proof: Dual-level access codes required to set or change all sensitivity settings and detection programs; one level for use by supervisors in selecting programs and sensitivity and the other for initial set-up and overall control; non-resettable sequence code logs all changes made whenever sensitivity codes are accessed. An audible alarm reports unauthorized attempts at access.
Infrared Sensor: Improves analysis of detection signal; increases throughput; helps eliminate "false alarms" and also provides accurate traffic counter.
Control Outputs: Solid state switches (low voltage AC or DC) for operating external alarms and control devices.
Masking: Programs designed to eliminate the problem of dissimilar targets canceling each other.
Construction: Attractive scratch and mar-resistant laminate with resilient end caps; control panel and cross members made of heavy duty aluminum.
Warranty: 24 months, parts and labor.

Dimensions:

Passageway Interior Size:
Depth 23" (0.58 m
Height 80" (2.03 m)
Width 30" (0.76 m)
Overall Exterior Size:
Depth 23" (0.58 m)
Height 87" (2.21 m)
Width 35" (0.90 m)
Shipping Weight:
135 lbs. (61.2 kg)
